SiBER 48
Sejak 2013 generasi ke-4 dari survei eksplorasi menggunakan metode Geolistrik dengan instrumen "SiBER 48" yang memiliki spesifikasi sbb :
1. Improved feedback circuit generator that allows you to work without interruption at no load and short-circuit;
2. Reduced measurement time;
3. Values increased mechanical strength of bearing structures;
4. Applied more reliable switch interface boards;
5. Improved performance of the generator;
6. Added protection against overheating of the transformer.
5. Improved performance of the generator;
6. Added protection against overheating of the transformer.
New generation of the device has successfully passed the tests field trials, as well as vibration test, shock and environmental testing in accordance with GOST 26116-84 .
Measurement with Siber-48 based on the resistivity methods. The fundamental physical law used in resistivity surveys is Ohm’s Law that governs
the flow of current in the ground. With equipment it is possible to work in 2D Electrotomography and Induced polarization modes.
Electrical exploration equipment “Siber-48” has built-in software that lets you :
– Program the switches for 2D Tomography;
– Ensure the safety of data when power failure;
– Perform control for each electrodes;
– Provides flexible equipment control.
the flow of current in the ground. With equipment it is possible to work in 2D Electrotomography and Induced polarization modes.
Electrical exploration equipment “Siber-48” has built-in software that lets you :
– Program the switches for 2D Tomography;
– Ensure the safety of data when power failure;
– Perform control for each electrodes;
– Provides flexible equipment control.
Setelah menghubungkan dua komponen 24-elektroda kabel dengan spasi 5 meter antara elektroda, ini memungkinkan untuk mendapatkan penampang geolistrik sepanjang lintasan lebih dari 235 meter dengan lama pengukuran kurang dari 10 menit.
Pada lintasan yang panjang diterapkan mode "Scolding Profile" dengan melakukan transfer segmen dari susunan kabel multi-elektroda dilokasi setelah pengukuran .
Software for PC – SibER Tools, butuh membuat dan edit file dengan deskripsi dari sequences-nya, seperti data primer saat prosesing - filtering, packaging dan export ke format yang umum (IPI2Win, Res2DInv dan Res3DInv). Program ini dapat membuat sequences baik elektro-tomografi dan tradisional sounding menggunakan 4 elektroda dengan linier atau perpindahan spasi secara geometric.
